Comments for Page: Brake
1. Included with the wheel motor.
2. Torque to 298–325 N•m.
3. Torque to 34–38 N•m.
4. Do not torque; the nut should be snug but allow the brake bellcrank to pivot freely.
5. The hub assembly includes the studs.
Item Part No. Qty Name
1 748913 2 CS .375-16x5.50 GR5 ZN
2 767954 12 FW 0.379X.82X.06 HD ZN
3 023655 4 NT 0.312-24 NL G8
4 768523 6 FW 0.343SAE
5 781583 2 BRAKE ROD ASSEMBLY
6 705178 2 CS .375-16X1.750HXG5
7 765339 4 BUSHING,IGUS#0608 (FS)
8 126643-3 1 BELLCRANK, LH
9 126644-3 1 BELLCRANK, RH
10 073858 2 FW .406X .750X.250 ZN
11 350397 2 BRAKE LINK TURNBUCKLE A
12 705160 2 CS .375-16X1.625HXG5
13 126646-3 1 EXTENSION, BRAKE ARM, LH
14 126645-3 1 EXTENSION, BRAKE ARM, RH
15 086660 6 NT .375-16NLG8
16 607896 2 DUST SHIELD
17 016832 4 NT .312-18FLKG5
18 607894 1 BRAKE ASSY, LH
19 607895 1 BRAKE ASSY, RH
20 607893 2 DRUM HUB ASSEMBLY
21 607328 8 CS .312-18X1.25HXG8 FL
22 037887 4 CB .312-18X 1.000 FUL ZN
23 601085 10 STUD, WHEEL LUG 1/2-20
Brake
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:23 UTC 2021 4-7
