Item Part No. Qty Name
1 1 ENGINE, KAW FX850V
2 788943 1 AIR FILTER INDICATOR
3 601216 1 FTG, ELBOW, STREET
4 796524 1 VALVE,OIL DRAIN M20x2.5
5 603012 1 MUFFLER, FX850V
6 767954 4 FW 0.379X.82X.06 HD ZN
7 602580 4 CS .375-16X1.25HXG8ZYP85
8 034272 2 NT .312-18HXG5
9 768523 5 FW 0.343SAE
10 036236 2 CS .312-18X1.000HXG5
11 113946 1 CLUTCH ANCHOR
12 606471 1 PULLEY, ENG 5.318 OP
13 212076 1 KEY 1/4 SQ X 1.50 LG(FS)
14 606404K 1 CLUTCH KIT
15 791251 1 HARNESS, CLUTCH PIGTAIL
Comments for Part Num. 791251
Pigtail was updated with epoxy to hold the wires steady. The wire sheath was also updated to a more flexible material.
16 000331 6 WIRE TIE, SMALL/SHORT
17 602680 1 FW .453X1.12X.12 HRD ZN
18 785659 1 CS .437-20X2.50 HXG5 P85
19 720516 1 CS M8-1.25X16HX FL10.9
20 796219 1 BATTERY CABLE,NEG 36" D
21 029876 1 LW .312 INTEXT ZN
22 744276 1 BATTERY CABLE POSITIVE
23 789131 1 CAP, HUSTLRZ FAN CON(FS)
24 000323 2 CLIP, HOSE CLAMP
25 015818 16.5" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
26 603326 32" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
27 603112 1 CLAMP, 3/16 FUEL
Engine, Muffler & Clutch (Multi-Page)
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:27 UTC 2021 6-1
