Comments for Page: Fuel System
1. Torque to 22 N•m.
2. Part of the wire harness.
FUEL & VAPOR LINE LENGTHS
Item Part No. Qty Name
1 603807 2 CAP, 3.5" RATCHETING GAS
2 607876 1 FUEL TANK ASM, LH FENDER
3 607877 1 FUEL TANK ASM, RH FENDER
4 603326 71.5" VAPOR LINE, 3/16"
Comments for Part Num. 603326
Sold by the foot.
5 015818 67" FUEL LINE, 1/4"
Comments for Part Num. 015818
Sold by the foot.
6 000323 4 CLIP, HOSE CLAMP
7 605215 65" FUEL LINE THERMAL SHIELD
Comments for Part Num. 605215
Sold by the foot.
8 604281 2 TEE, 3/16" PLASTIC
9 745059 1 FUEL VALVE 3-WAY
10 604323 1 VAPOR SYSTEM FILTER
11 036236 3 CS .312-18X1.000HXG5
12 079210 3 FW 0.344X1.0X0.06 ZN
13 043570 3 CLIP - HOSE - SINGLE(FS)
14 016832 3 NT .312-18FLKG5
15 712919 10 FW 0.406X1.00X.12 HD ZN
16 055822 10 CS .375-16X0.75 HX G5 ZN
17 055947 4 CS .250-20X0.50 HX G5 ZN
18 768515 4 FW 0.281SAE
19 123182 1 COVER, FUEL LINES
20 123181 1 COVER, FUEL SENDER
21 000331 2 WIRE TIE, SMALL/SHORT
Fuel System
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:30 UTC 2021 6-3
