Comments for Page: Instrument Panel & Wire Harness
1. Part of the wire harness.
2. Part of the Battery Assembly.
3. Part of the Fuel Assembly.
4. 607451 is used on mowers S/N 20070912 & HIGHER.
608041 is used on mowers S/N PRIOR TO 20070912.
5. The instrument panel includes the decal.
Item Part No. Qty Name
1 604241 1 WIRE HARNESS
2 055947 4 CS .250-20X0.50 HX G5 ZN
3 768515 4 FW 0.281SAE
4 000430 1 WIRE TIE, SMALL/LONG
5 606466 1 DECAL, INSTR PANEL
6 555786 1 SVC, INSTR PANEL
7 036236 3 CS .312-18X1.000HXG5
8 768523 3 FW 0.343SAE
9 043570 4 CLIP - HOSE - SINGLE(FS)
10 016832 3 NT .312-18FLKG5
11 000331 5 WIRE TIE, SMALL/SHORT
12 604307 1 MOUNT, PUSH BUTTON
13 776476 1 SWITCH, PTO 6201-321
14 607451 1 GAUGE, DUAL NEEDLE 12V
Not Shown 608041 1 FUEL GAUGE & SENDER KIT
15 712257 1 INDICATOR LIGHT, RED(FS)
16 786657 1 CABLE, CHOKE
17 603523 1 KNOB
18 601098 2 CB 10-24 X .500 ZYNC
19 785808 1 KEY ASSEMBLY
20 045898 1 IGNITION SWITCH
21 059832 4 NT #10-24 HX NL ZN
22 604373 1 RELAY CONTROL MODULE
23 063198 2 CS #10-24X0.750FLKG5
24 603475 1 CABLE, THRTL 43"
25 704932 2 FW 0.219X.50X.05 ZN
26 114052 1 KIT, CLUTCH CONN. REP.
27 601047 1 HOLDER, FUSE
Instrument Panel & Wire Harness
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:32 UTC 2021 7-1
