HUSTLER X-ONE Parts Manual

Comments for Page: Battery
1. When performing service on the mower, disconnect the negative battery cable (black) and do not reconnect it to the battery until ready to start the
engine.
Item Part No. Qty Name
1 794156 1 CS .250-20X2.750HXG5
2 601930 1 CS .250-20 X 6.50 HX G5
3 768515 2 FW 0.281SAE
4 029868 4 LW .250 INTEXT ZN
5 024927 2 NT .250-20HXG5
6 771428 1 BATTERY CBL BOOT-RED(FS)
7 604178 1 STRAP, TIE DOWN
8 055939 2 CS .250-20X0.75 HX G5 ZN
9 000331 4 WIRE TIE, SMALL/SHORT
10 124384-1 1 SUPPORT, CABLE
11 768523 5 FW 0.343SAE
12 036236 1 CS .312-18X1.000HXG5
13 034272 2 NT .312-18HXG5
14 034280 2 CS .312-18X0.750HXG5
15 016832 1 NT .312-18FLKG5
Battery
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:33 UTC 2021 7-2
