1. Torque to 85-99 N•m.
2. Torque to 4–8 N•m.
Item Part No. Qty Name
1 025007 2 CS .62511X1.750HXG5
2 028118 5 FW 0.625X1.00X.13 ZN
3 606460 1 GUIDE, BELT
4 608144 2 SHIELD, DUST
5 602821 2 IDLER, 6.0" COMMERCIAL
6 259812 1 CHAIN, 13 LINK
7 781302 1 IDLER SPRING
8 350884 1 SLIDE, DECK IDLER
9 603023 4 WN .312-18 ZN
10 602936 2 IDLER SLIDE, UHMW
11 025015 1 CS .625-11X2.500HXG5
12 602963 1 DUST SHIELD, IDLER LG
13 602838 1 IDLER, 8.0" COMMERCIAL
14 705954 14 CS .500-13X1.25 HX G5 ZN
15 752386 3 CW .515X 2.25X .204 BLK
16 212472 3 KEY 1/4 SQ X 1.00 LG(FS)
17 798967 3 PULLEY, B-SEC 5.44 EOD
18 045765 3 FW 1.030X1.50X.13 HD ZN
19 607409-4 3 DUST SHIELD
20 767962 13 FW .531 x 1.063 x .175
21 603022 4 CS .312-18X.625 BH ZN
22 607407 3 SPINDLE ASSY, DUCTILE
23 078949 1 CS .500-13X2.000 FUL HX
24 767954 1 FW 0.379X.82X.06 HD ZN
25 086660 1 NT .375-16NLG8
26 025395 1 CB .375-16X 1.00 G5 ZN
27 126117-1 1 DIVERTOR, DISCHARGE, 52"
28 781567 1 NT .500-13NLG5
Deck Pulleys & Spindles - S/N 20100049 & HIGHER
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:35 UTC 2021 8-2
