Item Part No. Qty Name
1 555439 1 SVC PULLEY COVER 52 RSCE
2 602562 2 DECAL, NO SERVICE
3 555440 1 SVC PULLEY COVER 52 LSCE
4 034280 4 CS .312-18X0.750HXG5
5 768523 4 FW 0.343SAE
6 604711 1 DECK BELT
7 126218-1 1 BRACKET, DISCHARE CHUTE
8 086660 10 NT .375-16NLG8
9 076422 3 FW 0.406X1.00X.06 ZN
10 606166 1 RETAINER, CHUTE SPRING
11 607787 1 SPRING, TORSION CHUTE
12 605916 1 DISCHARGE CHUTE
13 122148 1 BRKT, CHUTE BOTTOM
14 025395 9 CB .375-16X 1.00 G5 ZN
15 605936 1 PIN, CHUTE
16 781567 3 NT .500-13NLG5
17 767962 3 FW .531 x 1.063 x .175
18 602344 1 SPACER, ANTI- SCALP 5.73
19 602341 1 WHEEL, ANTI-SCALP
20 602338 1 CB .50-13 X 7.50 STD ZN
21 602345 2 SPACER, ANTI-SCALP 3.22
22 602263 2 WHEEL, ANTI-SCALP
23 607288 2 CB .50-13X4.75 STD ZN
24 016253 2 CB .312-18X .750 FUL ZN
25 605376 1 DECK BUMPER
26 079210 2 FW 0.344X1.0X0.06 ZN
27 604251 2 NT .312-18 HXNL JAM G2ZN
28 124086 1 PUSHER, W/A
29 015495 2 GREASE FITTING STRAIGHT
30 767954 6 FW 0.379X.82X.06 HD ZN
31 787721 3 BLADE,17.86"-H-F-CW
Not Shown 794198 3 BLADE,17.86"-MUL-F-CW
Not Shown 785436 3 BLADE,17.86"-GAT-F-CW
32 114988 3 SHIELD, BLADE BOLT
33 782474 3 CW .678 X 2.250 X .187
34 781872 3 CS .625-11X1.250HXG5
Deck, Deck Belt & Blades (Multi-Page)
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
