Item Part No. Qty Name
1 606918 1 MAGNETIC PIN, 1/2 x 3.13
2 086660 1 NT .375-16NLG8
3 767954 7 FW 0.379X.82X.06 HD ZN
4 718288 7 FW .516X.88X.09 ZN
5 124361-4 2 LATCH HANDLE
6 117489 1 SPACER, LATCH
7 124357-1 1 DECK HEIGHT W/A
8 604075 1 SPACER, CYLINDER
9 017251 3 CP .156DX1.000 LG HML Z
10 025965 2 CE .500X3.50 .156X3.34
11 041848 1 CB .375-16X 3.500 FUL Z
12 054502 4 NT .375-16HXG5
13 606895 1 SLIDER, DECK LIFT
14 068056 1 CE .500X1.50 .150X1.32
15 122994 1 DECK HEIGHT LINK, W/A
16 124291-1 1 PEDAL W/A
17 004168 5 FW .531x1.00x.090 ZN
18 074252 1 CS .500-13X1.50 HX G5 ZN
19 025395 4 CB .375-16X 1.00 G5 ZN
20 036244 2 CS .375-16X1.00 HX G5 ZN
21 761544 6 CS .500-13X2.250HXG8
22 122996 1 LINK SPACER
23 122987 1 DECK LIFT LINK, W/A
24 781567 5 NT .500-13NLG5
25 606316 4 NT 0.563-18 NLGC
26 606292 4 DECK LEVEL SPACER
27 061101 2 NT .750-10 HX ZN NL GR B
28 025296 4 FW .760X1.63X0.08 ZN
29 789115 2 CS .750-10X3.500HXG5
30 607979 4 DECK LEVEL PIVOT
Not Shown 606291 4 DECK LEVEL PIVOT
31 606290 4 W/A DECK LEVEL ROD END
32 767962 8 FW .531 x 1.063 x .175
33 606454 2 SPRING, EXT 7.0 300LB/IN
34 606478 2 EB, .500-13X3.00 FULTHD
35 008193 4 NT .500-13HXG5
Deck Lift & Deck Height (Multi-Page)
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:39 UTC 2021 8-6
