Item
Part No.
Qty
Name
Not Shown
607706
1
SEAT, I3M SEATS INC
1
607707
1
SVC, SEAT BACK COVER
2
608351
1
SVC, SEAT FOAM I3M
3
607708
1
SVC, SEAT CUSHION COVER
4
607166
1
SVC, ARM REST KIT
5
606081
2
SVC, ARM PADS
6
607207
1
SVC, SEAT BELT
7
607206
1
SVC, KNOB KIT
8
607205
1
SVC, BELLOWS
9
606082
1
SVC, OPS
10
607204
1
SVC, TRACK KIT
Seat Service Parts - 607706
52" X-ONE Parts Manual - 940056CE - HTX1TS052KAWFX850VC
Thu Feb 18 10:30:41 UTC 2021
9-2
69
71
Table of Contents
Default Chapter
3
Table of Contents
3
General Information
5
Frame & Engine Guard
6
Frame
6
Engine Guard
9
Transmissions, Drive Belt, Steering & Brake
11
Transmissions & Drive Belt
11
Transmission Service Parts
13
Steering
15
Steering Cover Assembly (Multi-Page)
17
Left Steering Box Assembly
20
Right Steering Box Assembly
23
Brake
25
Wheels & Tires Wheels & Tires
27
Front Wheel Assembly
29
Drive Wheel Assembly
31
Engine, Muffler, Clutch & Fuel System
33
Engine, Muffler & Clutch (Multi-Page)
33
Engine Service Parts
37
Fuel System
39
LS Fuel Tank Service Parts
42
RS Fuel Tank Service Parts
45
Instrument Panel, Wire Harness & Battery
47
Instrument Panel & Wire Harness
47
Battery
49
Deck, Deck Belt, Blades & Deck Lift
51
Service Deck
51
Deck Pulleys & Spindles - S/N 20100049 & HIGHER
53
Deck Pulleys & Spindles - SN PRIOR to 20100049
55
Spindle Assembly Service Parts - 607407
57
Deck, Deck Belt & Blades (Multi-Page)
59
Deck Lift & Deck Height (Multi-Page)
63
Seat & ROPS
67
Seat & Floor Pan
68
Seat Service Parts - 607706
69
Rops
71
