© EUROHEAT DISTRIBUTORS (H.B.S) LTD. Nov 2006
E & OE Instructions Part number IN1140 Ed A
2
Model Flue Size Air Requirement
Equivalent Area as
Approved Document J
UK Smoke Control
Exemption
Efficiency Net
%
Efficiency
Gross %
Vivaldi 6” (153mm) Nil Yes* 77 70.5
Beethoven 6” (153mm) Nil
Yes* 77 70.5
Mozart 6” (153mm) Nil
Yes* 77 70.5
Ravel 6” (153mm) Nil
yes* 77 70.5
Hwam 30 6” (153mm) Nil
Yes* 77 70.5
Monet 6” (153mm) 385mm
2 75 68.4
Figaro 6” (153mm) 551mm
2 73 67
Hwam 60 6” (153mm) 385mm
2 75 68.4
Dali 6” (153mm) 385mm
2 75 68.4
Technical Details
Model Name Heat Output
Nominal
Wood
Flue
Draught
Nominal
Heat
Output
Flue Gas
Mass Flow
g/s
Flue Gas
Temperature
deg C
Vivaldi 3.5kW 12pa 4.6 272
Beethoven 5.9kW 12pa 4.6 272
Mozart 7.9kW 12pa 4.6 272
Ravel 10.5 12pa 4.6 272
Hwam 30 3.5kW 12pa 4.6 272
Monet 5.7kW 13pa 6.2 267
Figaro 6kW 12pa 7.49 291
Hwam 60 5.7Kw 13pa 6.2 267
Dali 5.7kW 13pa 6.2 267
* The Hwam models Beethoven, Vivaldi, Mozart, Ravel and Hwam 30 are considered as exempt for use in smoke control areas if they
have been modified to ensure the air wash/secondary air control cannot be fully closed. If this modification has not been carried out
the appliance is not considered exempt under the Clean Air Act.
More information on alliance weight can be found in the hearths section of this manual.
Model Weight
Weight
with draw
Weight with
wood section
Weight with
Soapstone
Monet 150kg 150kg 147kg 245kg
Monet H 180kg 180kg 207kg 295kg
Monet with boiler 150kg
Mozart 88kg 88kg 85kg 111kg
Dali 151kg 156kg 151kg
Beethoven 95kg 114kg 95kg 160kg
Beethoven H 116kg 116kg 112kg 275kg incl. Draw
Vivaldi 78kg 93kg
Figaro 133kg
Ravel 108kg 108kg
Hwam30 87kg
Hwam 60 114kg
