A. 2 - 3 mmill. 1
ill. 2
Setting of Throttle
The throttle mechanics must have some play. Measure the distance covered by the
throttle lever before the engine reacts to the acceleration. The play should be 2-3 mm
(ill. 1).
Setting of throttle
Loosen the counter nuts at the end of the throttle cable. Then, turn them until the
required play is achieved.
Tighten the counter nuts again (ill. 2).
Setting of steering cable
Hold the steering in straight forward position (ill. 3).
The distance of the jet nozzle to the jet drive outlet must be the same on the left and
the right side (ill. 4). Otherwise, adjust the steering cable.
To disconnect the steering cable from the jet nozzle at the ball connection, you must
first pull the steering cable back. Then, pull up on the connection. The cable will be
free from the connection.
Loosen the counter nut at the end of the steering cable on the right-hand side
(Ill. 5).
Keep the steering always in straight forward position.
A. Throttle
B. Locknut
C. Throttle unit
english70
ill. 3
A
A
B
C
