Turn the cable connection to adjust the steering (ill. 6).
Apply a liquid glue to the nut before tightening it. Apply it to the counter nut
too after it has been adjusted correctly.
Reconnect the steering cable at the ball connection. Make sure the
connection locks securely over the ball.
As an additional check, turn the steering to the left and the right until the stop.
Measure the distance between the jet nozzle and the jet drive outlet in the
process.
The distance should be the same on both sides.
Checking of the steering cable
Please have this check only done by an official Hydrospace dealer.
If the steering is stiff or jerky, contact an official Hydrospace dealer.
71
ATTENTION
When not adequately assembled the nut/mother can solve itself. The
guidance characteristic can be impaired thereby. They control the locknut.
A. Jet nozzle
B. Stearing robe course
C. Locknut
D. Connection piece
A. Same distance ill. 4
ill. 5
AA
A
B
C
D
