HOLE TEMPLATE GUIDE
TOP
POSITION FOR 5/8” PAN HEAD
ALLIGNMENT SCREWS
(READ ALL INSTRUCTIONS
BEFORE DRILLING ANY HOLES!)
5-7/8” WIDE X 5-5/8” HIGH
HOLE IN STEEL WALL
