MAINTENANCE - CLEANING
1) Remove the safety screw.
2) Remove the detector from its base.
3) Thermistor area: use a small, soft bristle brush to dislodge any obvious contaminants such as insects, spider webs, hairs, et c.
4) Thermistor area: use a small vacuum tube or dry, clean, compressed air to suck up or blow any remaining small particles away.
5) Wipe the exterior housing of the detector with a clean, damp, lint-free cloth to remove any surface film that can later attract airborne
contaminants.
6) Install the detector onto its base again.
7) Test the detector.
8) Reinstall the safety screw.
TECHNICAL SPECIFICATIONS *
* See TDS-TWDTX technical specification document for further technical data.
** Detector’s rate of rise (A1R) / high temperature (BS) modes can be set through TauREX.
BATTERIES SPECIFICATIONS
* Batteries lifespan depends by environmental conditions, default monitor settings and link quality.
Specification Value
Communication range with TAU-TRM-01, TAU-CEM-01 or
TAU-EXM-01 network devices
200 m (in open space)
Wireless frequency band 868 MHz
Number of wireless channels 66
Radiated power 14 dBm (25 mW)
Temperature alarm threshold (A1R rate of rise setting) ** 58 °C
Temperature alarm threshold (BS high temperature setting) ** 78 °C
Operating temperature range -10 °C to 55 °C
Maximum humidity (non condensing) 95% RH
IP rating 40
Specification Value
Batteries type CR123A (3 V, 1.25 Ah)
Batteries lifespan * 10 years
Low battery threshold value (nominal) 2.850 V
Table 2
Table 3
WARNINGS AND LIMITATIONS
Our devices use high quality electronic components and plastic materials that are highly resistant to environ-
mental deterioration. However, after 10 years of continuous operation, it is advisable to replace the devices in
order to minimize the risk of reduced performance caused by external factors. Ensure that this device is only
used with compatible control panels. Detection systems must be checked, serviced and maintained on a
regular basis to confirm correct operation. Smoke detectors may respond differently to various kinds of
smoke particles, thus application advice should be sought for special risks. Detectors cannot respond correct-
ly if barriers exist between them and the fire location and may be affected by special environmental condi-
tions. Refer to and follow national codes of practice and other internationally recognized fire engineering
standards. Appropriate risk assessment should be carried out initially to determine correct design criteria and
updated periodically.
Use only in Taurus fire detection and alarm systems.
WARRANTY
All devices are supplied with the benefit of a limited 3 years warranty relating to faulty materials or manufac-
turing defects, effective from the production date indicated on each product. This warranty is invalidated by
mechanical or electrical damage caused in the field by incorrect handling or usage. Product must be returned
via your authorized supplier for repair or replacement together with full information on any problem identified.
Full details on our warranty and product’s returns policy can be obtained upon request.
Hyfire Wireless Fire Solutions Ltd -
Unit B12a, Holly Farm Business
Park, Honiley, Warwickshire, CV8
1NP - United Kingdom
20
HF-20-016CPR
TAU-TH-01
EN 54-25:2008
EN 54-5:2000 + A1:2002
Class P (A1R / BS)
0051
info@hyfirewireless.co.uk L20-TWDT1-1400 (vA.4)
