Lodging Quickstay Application
Quick Reference Guide
Check-in/Sale
> Swipe card or input account # and
press [ENTER]
> If prompted, input last 4 digits of account
# and press [ENTER]
> If prompted, input expiration date
(MMYY) and press [ENTER]
> Input $ amount and press [ENTER]
> Terminal will prompt to input check-out
date:
• Input date (MMDDYY) and
press [ENTER]
• Press [ENTER] for current date
> Print second receipt – [YES/NO]
Sale – No Show, Ret/Rest,
Delayed Charged or Card
Deposit
> Press [*]
> Swipe card or input account # and press
[ENTER]
> If prompted, input last 4 digits of account
# and press [ENTER]
> If prompted, input expiration date
(MMYY) and press [ENTER]
> Input dollar amount and press [ENTER]
Terminal displays:
1 = NSH (No Show)
2 = RTL/RST (Retail/Restaurant)
3 = DLY (Delayed Charge)
4 = DEP (Card Deposit)
> Input the charge type (1, 2, 3 or 4) and
press [ENTER]
> If prompted, input the check-in/out date:
• Input date (MMDDYY) and press
[ENTER]
• Press [ENTER] for current date
> Print second receipt – [YES/NO]
Refund
> Press [REFUND]
> Swipe card or input account # and press
[ENTER]
> If prompted, input last 4 digits of account
# and press [ENTER]
> If prompted, input expiration date
(MMYY) and press [ENTER]
> Input $ amount and press [ENTER]
Terminal displays:
1 = NSH (No Show)
2 = RTL/RST (Retail/Restaurant)
3 = DLY (Delayed Charge)
4 = DEP (Card Deposit)
> Input appropriate option press [ENTER]
> If prompted, input the check-in/out date:
• Input date (MMDDYY) and
press [ENTER]
• Press [ENTER] for current date
> Print second receipt – [YES/NO]
