HyperX QuadCast User Manual

Documento No. 480HX-MICQC.A01
HyperX QuadCast
TM
Página 4 do 16
Especificações
Microfone
Consumo de Energia: 5V 125mA
Taxa de bits/amostra: 48kHz/16-bits
Elemento: Microfone condensador Electret
Tipo de condensador: Três condensadores de 14 mm
Padrão polar: Estéreo, Omnidirecional, Cardióide, Bidirecional
Resposta de frequência: 20Hz - 20kHz
Sensibilidade: -36dB (1V/Pa a 1kHz)
Comprimento do cabo: 3m
Peso:
 Microfone: 254g
 Base shock mount e pedestal: 364g
 Total com cabo USB: 710g
Saída do fone de ouvido
Impedância: 32 Ω
Resposta de frequência: 20Hz - 20kHz
Máxima saída de energia: 7mW
THD: ≤ 0.05% (1kHz/0dBFS)
SNR: ≥ 90dB (1kHZ, RL=∞)

HyperX QuadCast Specifications

General

Headphone out	Yes
Device interface	USB
Connectivity technology	Wired
Cable length	3 m
Product color	Black, Red
Country of origin	China
Operating voltage	5 V
Power consumption	125 mA
Type	Table microphone
Bit rate	16 bit
Sample rate	48 kHz
Microphone frequency	20 - 20000 Hz
Microphone sensitivity	-36 dB
Stand weight	364 g
RMS rated power	0.007 W
Output impedance	32 Ω
Total Harmonic Distortion (THD)	0.05 %
Line-out Signal-to-Noise Ratio (SNR)	90 dB
Package depth	174 mm
Package width	150 mm
Package height	280 mm
Package weight	1190 g
Export Control Classification Number (ECCN)	-
Commodity Classification Automated Tracking System (CCATS)	85181095

Weight and Dimensions

Microphone weight	254 g
