Hypex Electronics UcD180 Stereo kit - System Information; Advanced System Information

24
2x
❺
❹
2x
❸
❷
25
Pinout:
Neutrik NC3FXX-B or -BAG (female)
Balanced XLR connection:
This information is given for reference and to guide
you in connecting your DIY-kit in the correct way.
Do not modify the internal wiring of the kit other
then specified in the instructions.
Neutrik NC3MXX-B or -BAG (male)
Pin 2: Positive (+ or hot)
Pin 3: Negative (- or cold)
Pin 1: Shield
Advanced system information
Output Impedance:
20mΩ f < 1kHz
150mΩ f < 20kHz
(weight for the total assembled kit)
External size (WxHxD): 200 x 79 x 280 mm
UcD180 stereo kit: 2.74 kg
Distortion:
Dimensions and weight
(size incl feet, excl connectors)
0.1% @ 20Hz < f < 20kHz Pout<PR/2
Load impedance: min 1Ω
Performance:
Voltage Gain: 25.5 - 26.5dB
Source impedance: max 7kΩ
Operation:
Power Bandwidth: 20 - 35kHz
For more detailed information please refer to the
datasheet of each individual product on our
website.
Frequency Response: 10Hz - 50kHz
Connector: 3-pin IEC 250Vac, 10A male.
Technology:
Input sensitivity:
2
Low Line input voltage: 100 - 120Vac ±10%*
High Line input voltage: 200 - 240Vac ±10%
Line input power
Line input frequency: 47 - 63 Hz
Depending on load, 470W max
180W 4Ω @ 1.35V
Input power:
Channels:
Output power in 8 < 1% THD+N :Ω @
UcD®
Output:
Binding post
Input:
Output power in 4 < 1% THD+N :Ω @
Stereo XLR
** Both channels driven
120W**
180W**
* With jumper placed
System information UcD180 stereo kit
