MAINTENANCE
70
1. BATTERY
2. RESERVO IR, BRAKE FLUID
3. DIPSTICK, HYDRAULIC OIL
S70--120XL
S135--155XL
11725
11618
4. BREATHER, HYDRAULIC TANK
5. BREATHER, ENGINE
6. FILL CAP, HYDRAULIC OIL
7. FILTER HEAD
1
2
3
4
5
6
7
3
NOTE: BREATHER IS
ON TOP OF
HYDRAULIC TANK AND
UNDER THE TOP OF
THE FRAME.
FIGURE 8. MAINTENANCE POINTS
