Hyster N30XMXDR3 Service & Repair Manual

Table 1. Maintenance Schedule
Item
8 hr
or 1 day
350 hr
or 2
month
2000 hr
or 1 year
Procedure or
Quantity
Specification
No. Description
20 Safety Labels and
Operating Manual
X Replace if Necessary
See Parts Manual
21 Battery X X Check Water Level
Equalization Charge
3
18 Brake X Check Operation
X Check Operation Hold 10% grade with
rated load
X Visually Inspect
Brake
No Visible Damage
8 Drive Tire and Load
Wheels
X Check for Damage Replace as Necessary
1 Mast X Check Condition
Channel Wear
Surfaces
X and L Clean and Lubricate Multipurpose
Grease
1
Wear Plugs X and L Clean and Lubricate Multipurpose
Grease
1
22
Lift Chains
4
X Check Condition SAE 20W or 30W
Motor Oil
X
2
and L
Clean, Check, and
Lubricate
4 Forks X Check Condition and
Operation
Check With Fork
Gauge
Fork Guides
and Lock Pins
X L Lubricate Pins and
Sliding Surfaces
SAE 20W or 30W
Motor Oil
6 Reach Assembly X Check Condition
Channel Wear
Surfaces
6
X and L Clean and Lubricate Multipurpose
Grease
1
12 Hydraulic System
Hydraulic Oil X C Change Oil in MDU
Hydraulic Oil
5
To Correct Level
Breather Cap X Clean or Replace
Hydraulic
Oil Strainer
X Clean or Replace
Hydraulic
Hoses and
Fittings
X Visually Inspect Replace as Required
X=Check C=Change L=Lubricate
Maintenance Schedule 8000 SRM 1027
12

Hyster N30XMXDR3 Specifications

General

Brand	Hyster
Model	N30XMXDR3
Category	Lifting Systems
Language	English
