8-2
2. 3 STAGE MAST(MAST)
1
11
5
6
10
9
12
3
2
4
7
3
2
4
8
Lift
cylinder
Lift
cylinder
Free lift
cylinder
11
110D7EMS05
1 Outer mast
2 Shim
3 Roller bearing
4 Side roller bearing
5 Tilt cylinder pin
6 Mast mounting pin
7 Inner mast
8 Middle mast
9 Sheave
10 Anchor bolt
11 Chain
12 Sheave bracket
