947
Maintenance
Engine compartment main fuse panel
Fuse No. Symbol Fuse rating Protected component
1
100A E/R Fuse & Relay Box (FUSE : F3, F4, F5)
2
50A I/P Fuse & Relay Box (Tail Lamp Relay, FUSE : F26, F24, F25, F27)
3
30A E/R Fuse & Relay Box (RLY. 2)
4
50A EPS Control Module
5
40A E/R Fuse & Relay Box (RLY. 5), Ignition Switch
6
40A Ignition Switch
7
50A
E/R Fuse & Relay Box (FUSE : F20, F18, F19, F17), I/P Fuse & Relay Box (POWER
CONNECTOR : F1,F2, FUSE : F29, F5, F6, F7) E/R Fuse & Relay Box (FUSE : F14)
8
30A E/R Fuse & Relay Box (RLY. 1)
9
30A E/R Fuse & Relay Box (RLY. 6)
10
20A Ignition Coil
11
10A
E/R Fuse & Relay Box (RLY. 4, RLY. 6), ECM, Camshaft Position Sensor, Oxygen Sensor (Down),
Purge Control Solenoid Valve, Oxygen Sensor (Up), Crankshaft Position Sensor
To Next Page
