1
FEATURES OF YOUR HYUNDAI
11
B080G01HR-GAT
Center Seat (With Seatback Con-
sole Compartment) (If Installed)
HHR2048
o To use the console compartment,
push down the lever and tilt the
seatback forward.
o To use the center seat, lift up the
seatback until it locks into position.
CAUTION:
When lifting up the seatback, do not
place any object on the console com-
partment.
!
Lever
B110B02HR-GAT
REAR SEAT (If Installed)
Rear Seat Cushion Under Box
There is mutipurpose receipt space
under the rear seat cushion.
B110B01HR
HHR2052
!
To use the rear seat cushion under box,
pull up the clamp levers on the both
sides of the cushion and unhook the
clamp from the seat cushion's hook.
And then, pull the strap on the seat
cushion.
WARNING:
When you return the seat cushion to
its original position, make sure the
seat belts are in position to be acces-
sible and to function properly.
To Next Page
