Hyundai HYM3800E User Manual

Operation
24
www.hyundaipowerproducts.co.uk
01646 687 880 sales@hyundaipowerproducts.co.uk
To remove the plug, lift the rear flap on the mower and pull out the mulching plug.
Mulching
1
2
To install the plug, lift the rear flap and clip into the two bottom catches. Close the rear flap.
This can be used to prevent the grass clippings from entering the collector box. The
clippings will be mulched up, leaving the nutrients to be absorbed back into the lawn.
What Is Mulching?
Mulching is the intelligent way to keep your lawn healthy. This is when the grass clippings are
cut into fine pieces which then fall back into the soil. These fine pieces are rich in nutrients and
act as a natural fertiliser. This will keep your lawn healthy.
This is the
mulching plug.
You must turn motor off before removing or installing the mulching plug.

Hyundai HYM3800E Specifications

General

Type	Push lawn mower
Cutting width	380 mm
Grass catcher	Yes
Product color	Black, Blue
Number of wheels	4 wheel(s)
Rotational speed	3700 RPM
Maximum lawn area	185 m²
Maximum cutting height	70 mm
Minimum cutting height	20 mm
Grass collecting volume	40 L
Number of height positions	5
Power source	AC
AC input voltage	230 V
AC input frequency	50 Hz

Weight and Dimensions

Depth	1320 mm
Width	450 mm
Height	920 mm
Weight	12500 g
Package depth	700 mm
Package height	410 mm
Package weight	14000 g
