Hyundai Power Equipment
Pressure Washer Pump (HYW2500P)
No. Part Code Description Qty. No. Part Code Description Qty.
1 BA1007 Manifold 1 39 DA2107 Screw - M6 1
2 DA2114 Screw - M8 x 45 5 40 DA5023 Handle 1
3 DA5027 Jacket 1 41 DA3017 Valve seat 3
4 DA8999 Thermal valve 1 42 DA1035 Cap 1
5 DA1010 Injector 1 43 DA2119 Screw - M8 x 20 4
6 DA7981 O-ring - 4 x 1.8mm 1 44 AD1121 Inlet lter 1
7 DA3001 Spring 1 46 DA7213 Main ring 3
8 D43006 Ball - Þ5.556 1 47 DA7993 O-ring - 14 x 1.8mm 1
10 DA1033 Injector body 1 48 DA1018 Ring seat 3
11 DA7986 O-ring - 14 x 1.8mm 1 49 DA7977 O-ring - 20 x 1.8mm 3
12 DA7992 O-ring - 10 x 1.8mm 2 50 DA7220 Ring seat 3
13 DA3045 Spring 1 51 DA7205 Oil seal 3
14 DA1036 Check valve 1 52 DA3097 Piston 3
15 DA7989 O-ring - 4.3 x 9.1 x 2.4mm 1 53 DA3042 Spring 3
16 DA3099 Screw 1 54 DA3095 Spring seat 3
17 DA3023 Valve seat 3 55 DA3064 Snap ring 3
18 DA3048 Valve plate 6 56 BA4098 Support 1
19 DA7984 O-ring - 8 x 1.8mm 9 57 DA7978 O-ring - 90 x 2.65mm 1
20 DA3049 Spring 6 58 BA4097 Crankcase cover 1
21 DA5012 Valve guide 6 59 DA7973 O-ring - 11.8 x 2.65mm 1
22 DA7990 O-ring - 11.2 x 1.8mm 3 60 DA1015 Oil discharge cap 1
23 DA1030 Valve cap 3 61 DA5009 Oil cap 1
24 DA3026 Valve seat 1 62 DA7971 O-ring - 13.2 x 1.8mm 2
25 DA7991 O-ring - 11.6 x 1.8mm 2 63 DA5007 Oil Dipstick 1
26 DA3029 Valve head 1 64 DA3510 Bearing 1
27 DA3025 Valve guide 1 65 BA4099 Eccentric shaft 1
28 DA5013 Back ring 1 66 DA3047 Bushing 1
29 DA7982 O-ring - 6 x 1.8mm 1 67 DA3509 Bearing 1
30 DA5014 Back ring 1 68 DA7203 Oil seal 1
31 DA3027 Bushing 1 69 DA2117 Screw - 5/16-24 UNF x 25 4
32 DA3024 Rod 1 70 D32001 Washer 4
33 DA7988 O-ring - 17.17 x 1.78mm 1 91 BA9007 Suct/del valve ass. kit 1
34 DA1038 Bushing 1 92 BA9024 Suction valve ass. kit 1
35 DA1039 Spring seat 1 93 BA9018 Regulation valve ass. kit 1
36 DA3021 Spring 1 94 BA9010 Oil cap kit 1
37 DA1041 Spring spacer 1 95 BA9023 Water seal kit 1
38 DA1040 Adjustable knob 1 96 BA9016 Oil seal kit 1
