Maintenance
687
Type B
1. Remove the light assembly from the
vehicle by prying the lens and pulling
the assembly out.
2. Reinstall a new light assembly to the
body of the vehicle.
Rear combination light bulb
replacement
(1) Stop and tail light
(2) Rear turn signal light
(3) Back-up light
(4) Tail light
Outside light
1. Open the tailgate.
2. Loosen the light assembly retaining
screws with a cross-tip screwdriver.
3. Remove the rear combination light
assembly from the body of the vehicle.
OLM079050
OLM079033
OLM079034
OLM079035
