Engine Compartment Overview
Smartstream G1.6 T-GDi
1C_EngineRoom
The actual engine compartment in the vehicle may differ from the illustration.
(1) Engine coolant reservoir ........................................................................................9-22
(2) Battery .....................................................................................................................9-32
(3) Brake fluid reservoir ...............................................................................................9-24
(4) Air cleaner ...............................................................................................................9-26
(5) Engine oil filler cap ................................................................................................. 9-19
(6) Engine oil dipstick ...................................................................................................9-20
(7) Windshield washer fluid reservoir .........................................................................9-25
(8) Fuse box ................................................................................................................. 9-48
