Maintenance
Description Fuse rating Protected Component
A/BAG IND 10A Instrument Cluster
A/BAG 15A ACU, A/C Control Module, Passenger Occupant Detection Sensor
MODULE 5 7.5A
Sunroof_MTR, RAIN_SNSR,RR_BLOWER,PGS, AC_INVERTER_UNIT,Smart Key Control Module,
BCM, Rear Seat Warmer LH/RH,Driver/Passenger Seat Warmer Module,
MODULE 1 7.5A Sport Mode Switch, Key Solenoid, Console Switch LH/RH,Rear Power Window Switch LH/RH
FOG LAMP RR 10A RR_FOG_LH/RH
MEMORY 2 10A
BCM, Tire Pressure Monitoring Module, Electro Chromic Mirror, Driver/Passenger Door Module, Auto
Light & Photo Sensor, Data Link Connector, A/C Control Module, Instrument Cluster, FRT_DRV_SEAT
SMART KEY 2 7.5A Smart Key Control Module, Immobilizer Module
MODULE 3 10A
BCM, Instrument Cluster, Tire Pressure Monitoring Module, A/C Control Module, Driver/Passenger
Door Module, ATM Shift Lever Indicator, Rear Seat Warmer LH/RH, 4WD ECU, Driver/Passenger Seat
Warmer Module, MTS Module, Rear(SMART) Parking Assist Sensor LH/RH, A/V & Navigation Head
Unit, Rear Parking Assist Sensor (Center)LH/RH, AMP, SAS_ESP,EPB_EXT, Electro Chromic Mirror,
BSD
SMART KEY 4 10A Start/Stop Button Switch, Immobilizer Module
INTERIOR LAMP 15A
Cargo Lamp, Vanity Lamp LH/RH, Overhead Console Lamp, Center Room Lamp, Personal Lamp
LH/RH
MULTI MEDIA 15A Audio, A/V & Navigation Head Unit, MTS Module,D_CLOCK
MDPS 7.5A MDPS Unit
HTD STRG 15A Steering Wheel Switch
MEMORY 1 10A RF Receiver, Ignition Key Ill. & Door Warning Switch
