7-69
7
Maintenance
Engine compartment main fuse panel
Fuse Name Fuse rating Protected Component
MULTI
FUSE
(TYPE A)
IG2 30A IGPM (Fuse - F8/F25/F31/F38/F42)
BLOWER 40A RLY. 9 (Blower Relay)
2
AHB 40A Integrated Brake Actuation Unit
1
AHB 40A Integrated Brake Actuation Unit
REAR HEATED 50A RLY. 12 (Rear Heated Relay)
3
B+ 50A IGPM (IPS2 (4CH), IPS3 (4CH), Fuse - F28/F29)
5
B+ 50A PCM Block (Fuse - F4/F5/F6/F13/F14/F18/F22, Engine Control Relay)
EEWP 60A Electric Water Pump
1
MDPS 80A MDPS Unit
MULTI
FUSE
(TYPE B)
IG1 40A IGPM (Fuse - F14/F19/F20/F26/F27/F33/F34/F40/F41/F47/F46)
POWER OUTLET 40A RLY. 10 (Power Outlet Relay)
2
B+
50A IGPM (IPS1 (4CH), IPS4 (4CH), IPS5 (4CH), Fuse - F36/F42)
1
B+ 60A IGPM (Fuse - F1/F2/F10/F13/F17/F18/F23/F24/F30, Power Window Relay)
COOLING FAN 60A RLY.2 (Cooling Fan Relay)
FUSE
DEICER 20A RLY. 6 (Deicer Relay)
1
OPCU 20A Electric Oil Pump Unit
1
HEV ECU 10A HPCU
