SERVICE MANUAL
Applies to: Hyundai Coupe/Tiburon 1998-2000
GROUP
Restraints
SRS Air Bag System
Return to Main Menu(s): Mechanical Manual Electrical Manual
DTC - B1346, B1347
DTC CODE
DISPLAY ON HI-SCAN
CONDITION
B1346 DAB resistance - High
Ignition switch "ON" or start release
DAB module malfunction > 3.6 - 6.7
OHM
B1347 DAB resistance - Low
Ignition switch "ON" or start release
DAB module malfunction > 0.6 - 1.9
OHM
CHECK ITEMS
Short circuit in DAB harness
DAB module malfunction
Clock spring malfunction
SRS control module malfunction
CHECK PROCEDURES
The SRSCM shall measure the resistance of the DAB to detect a resistance which lies outside the allowed range. Do
not attempt to measure the resistance of DAB squib.
Before inspection,
Disconnect the battery negative (-) terminal cable and wait at least 30 seconds.
Remove the DAB connector and PAB connector.
CHECK INFLATOR CIRCUIT
Turn ignition switch to lock, and disconnect the negative (-) terminal cable from battery and wait at least 30 seconds.
Disconnect SRSCM connector. (Refer to BD section for removal of center console box)
Connect the SRS harness checker to DAB harness side connector & SRSCM harness side connector.
Check the terminal of checker and the limit is as following.
Terminals
B1346
B1347
5 to 13
Continuity
-
6 to 14
Continuity
-
