7-59
7
Maintenance
Fuse Name Fuse rating Circuit Protected
P/SEAT (DRV) 20A Driver Seat Manual Switch
HTD MIRR 7.5A Rear Defogger Switch, Driver Power Outside Mirror, Passenger Power Outside Mirror
A/BAG 10A SRS Control Module, Tell Tail Lamp, Passenger Occupant Detection Sensor
MDPS 10A MDPS Unit
A/CON 7.5A A/C Control Module
SMART KEY 10A Fob Holder, Start/Stop Button Switch, PDM, Smart Key Control Module
SAFETY POWER WINDOW 20A Driver Safety Power Window Module
A/BAG IND 10A Net Used
MODULE 1 10A
ESC Off Switch, BCM, Smart Key Control Module, CSD Switch, PDM, Tire Pressure
Monitoring Module, Multifunction Switch, Rear Parking Assist Sensor, Rear Impact Sensor,
Code Division Multiple Access, Gear Differential Unit, MCU, Stop Lamp Switch, Cooling Fan
Motor LH, Cooling Fan Motor RH, E/R Fuse & Relay Box (ATM P/N Relay)
B/UP LAMP 10A
Rear Combination Lamp (In) LH/RH, ATM Shift Lever ILL., BCM, A/V & Navigation Head Unit,
Electro Chromic Mirror
TPMS 7.5A
E/R Fuse & Relay Box (Shift Lock Relay), ATM Shift Lever, Tire Pressure Monitoring Module,
Rear Parking Assist Buzzer
CLUSTER 10A
A/C Control Module, Seat Belt Reminder Switch, Console Switch, Instrument Cluster,
A/V & Navigation Head Unit, ATM Shift Lever ILL., E/R Fuse & Relay Box (PTC Heater Relay)
H/LAMP HI 10A E/R Fuse & Relay Box (H/LAMP HI Relay)
DR LOCK 15A Door Lock/Unlock Relay, Tail Gate Relay, ICM Relay Box (Two Turn Unlock Relay)
S/HEATER RR 15A ICM Relay Box (Rear Seat Warmer Relay LH/RH)
PDM 2 15A PDM
HAZARD 15A ICM Relay Box (Flasher Sound Relay), BCM
