I-Inc AG191D User Manual

19" LCD Color Monitor I-INC AG191D
4
1. Monitor Specifications
Driving system TFT Color LCD
LCD Panel Size 48cm(19.0")
Pixel pitch 0.294mm(H) x 0.294mm(V)
Video
R,G,B Analog Interface
Digital(Dual-Input Model)H/VTTL
Input H-Frequency 31KHz – 80KHz
V-Frequency 55 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1280 x 1024 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode ≤36.7W
EPA ENERGY STAR
®
OFF Mode ≤2W
Audio output Rated Power 1.5W rms (Per channel)
Input Connector
D-Sub 15pin
DVI-D 24pin (Dual-Input Model)
Maximum Screen Size
Hor. :376.32mm
Ver. :301.056mm
Power Source 100~240VAC,50/60HZ
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 60°C
Operating Humidity: 20% to 80%
Dimensions
406(W)×408 (H)×210(D) mm
16.0”(W)×16.1”(H)×8.3”(D)
Weight (GW/NW)
6.5 kg / 5.0 kg
14.3lb/11.0lb
