User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 48.2cm(19.0")
Pixel pitch 0.2835mm(H) x 0.2835mm(V)
Video H-Frequency 31KHz – 80KHz
V-Frequency 56 – 75Hz
Display Colors 16.2M Colors
Max. Resolution 1440 x 900 @75Hz
Plug & Play
VESA DDC2B
TM
ON Mode
≤ 55W
EPA ENERGY STAR
®
OFF Mode
≤ 1W
Input Connector
D-Sub 15pin
DVI-D 24pin (Dual-Input Model)
Maximum Screen Size
Hor. :408.24mm
Ver. :255.15mm
Power Source 90~264VAC,47~63HZ
Environmental
Considerations
Operating Temp: 5° to 40°C
Storage Temp.: -20° to 65°C
Operating Humidity: 20% to 80%
Dimensions
446 (W)×362.85 (H)×213.6 (D) mm
17.56”(W)×14.29”(H)×8.4”(D)
Weight (GW/NW)
5.7 Kg / 4.4K g
12.6 lb/9.7 lb
*** The above specification is subject to actual product specification and is subject to
change without prior notice.
19
