Modes 8 bit standard resolution
1 1 x RGB over 4 cells
3 1 x RGB over 4 cells with an overall master and strobe
5 4 x RGB
7 4 x RGB with an overall master and strobe
9 4 x RGB each with individual master and strobe
16 bit high resolution (recommended)
2 1 x RGB over 4 cells
4 1 x RGB over 4 cells with an overall master and strobe
6 4 x RGB
8 4 x RGB with an overall master and strobe
10 4 x RGB each with individual master and strobe
note 16 bit for every channel bar strobe which runs as 8 bit
Note; please refer to power box or user instructions or website for channel allocation details. Most
popular lighting desks have personalities available for download from their respective websites or the
downloads section on our website.
Light Engine
Source Customised lamina Titan RGB LED
Wavelengths Red 625 Nm +/- 2.5 Nm
Green 517 Nm +/- 2.5 Nm
Blue 452.5 Nm +/- 2.5 Nm
Optics 4 x evenly spaced 20 degree optic
note: further photometric data and IES files are available for download from our website
Thermal characteristics
Fixture front Passive convection cooled
Power box Force air cooled via low airflow/ low noise fans, mounted to the base
Operating temperature
Minimum -20 degrees C
Maximum + 46 degrees C
Weather protection
Fixture front Hermetically sealed to IP67
Power box Mounted horizontally facing upwards
Rated to IP65H
Humidity max 20% ~ 90% RH non-condensing
Approvals & Compliance
BS EN 55103-1 Harmonics BS EN 55103-2 Immunity BS EN 61000-3-2 Emissions
USA / Canada ETL pending
Lead and mercury free return to manufacturer for recycling
IP Protection Patents filed in USA
Manufactured in the United Kingdom by
We reserve the right to improve this fixtures design.
BB4 USERS MANUAL - PAGE 24
