BB 4 Washlight tech spec
BB4 USERS MANUAL - PAGE 23
Dimensions
Length 600 mm
Height 301 mm on rubber feet
Width 147 mm
Weight 13.5Kg total
Yoke: 3 KG
Power Box: 4.5Kg
BB4 batten: 6Kg
Mechanical design/ materials used
Batten Aluminium shrouded finned diagonal heatsink
Power box Aluminium with steel base
Yoke Folded and welded steel
Finish Electro static powder coated black satin
Rigging
Style 16 ¼ turn camloc fasteners
Number of positions 8 rigging locations on yoke
Accessory holder Fitted with sprung retention flap
Conventional mounts 2 of 12mm bolt holes fitted at each yoke end
Note: unit comes with three scaffold clamp adaptors to accept 12mm bolts, equipped with
two camloc ¼ turn bolts
Electrical connections for mains and data in/out
Combined power and data connection
Input Chassis mounted male IP67 6 pin
Output Chassis mounted female IP67 6 pin
Fixture feed Chassis mounted female IP67 7 pin
Fixture feed Trailing 7 pin male
Mains and data
Input inline female 6 pin Ceep
Output 6 pin Ceep
Electrical
120 watts total power on full.
Input 90- 265 Volt 50/60 Hz
Power 0.5 amps @ 240 volts
Fuse 20mm x 5mm slow blow 2 amp
Output to fixture 15 volts max
Data type USITT DMX512-A
Note; units comes complete with 16 amp cee form plug and 5 pin xlr male. A 1
metre combined power cable link is also supplied.
Control RGB additive colour mixing
DMX channels 3 channels minimum 36 channels maximum
User interface weatherproof backlit lcd display with
four membrane switches
