13
INSTALLING THE LEGS
FF
DD
N
M
x2
x4
Do not overtighten.
Install tube to both legs.
M
10.1
10.2
AA
S1
x4
10
INSTALLING THE DOOR BRACKETS
L
x12
The door brackets must point downward. Install the door brackets
in alignment with the support bars on the bed frame.
AA
Top
Bottom
AA
W
x 24
11
* Install the handle on the other side of the door during this step.
Decorative handle not included. Handle should be mounted
at a height to comfortably allow the user to pull the bed down
(approximately 1/3 of the way down from the top of the door).
x 6
x12
10
3/8”
27
5/16”
27
5/16”
10
3/8”
30
3/4”
30
3/4”
6”
6”
Measurements (right) are for the
placement of this hole on the
backside of the doors.
Secure the legs to the bed frame.
To Next Page
