Technical Specifications
Antenna
Receiver Frequency: 1575.42 MHz (L1 band) C/A code
Antenna Type: Built-in Active Antenna
GPS Receiver
Technology: MTK MT3301 + MT3179 GPS Module, WAAS enabled
Satellite Measure Used: 32-channel parallel automatic selection
Tracking Sensitivity: -158 dBm
Operating Temperature: -10°C to 60°C
Battery: 1050 mAh Li-Ion rechargeable battery
Operating Time: Up to 27 hours
Standby Time: More than 300 hours
Bluetooth
Standard: Fully compliant with Bluetooth V1.2
Output Power: 0dBm (Typical), Class II
Range: Up to 10 meters
Bluetooth Profile: Serial Port Profile (SPP)
Frequency: 2.4GHz~2.4835GHz ISM Band
Time to First Fix (TTFF)
Reacquisition: 0.1 seconds typical
Hot Start: 1 seconds typical
Warm Start: 33 seconds typical
Cold Start: 36 seconds typical
Accuracy of Position Fix
Horizontal: 3.0m 2D-RMS; <3m CEP(50%) without SA(horizontal);
DGPS (WAAS, EGNOS, MSAS): 2.5m
Velocity: 0.1/sec 95% without SA
Receiver Configuration
Baud Rate: 4800/9600/14400/19200/38400/57600/115200 bps
Update rate: Once every second
Output Message: NMEA 0183 v3.01 Default: GGA, GSA, GSV, RMC
Physical Characteristics
Dimension: 69.6 x 47.3 x 19.2mm
Weight: 72g
Support Information
Support Phone number: (626) 574-0279
Support Email: support@itrekgps.com
