Ibanez IBZ10 - Mechanical and Chassis Components; Heatsinks and Thermal Components; Fasteners and Hardware; Chassis and Cabinet Parts

ITEM NUMBER
REMARK Q'TY
DESCRIPTION
IBZ10 PARTS LIST
32S00060 B5 01 HEATSINK HSK-33 HSKP74294233 1
32S00061 B5 01 205 CONNECT WIRE HSN20XX2802A 1
32S00062 B5 01 205 CONNECT WIRE HSN20XX2800A 1
32S00063 B5 01 MICA SHEET TO220 SPTMGATO220X 2
32S00064 B5 01 TR INSLT PLATE PPTTWH203530 2
32S00065 B5 01 SCREW NI M3 P0.5 MSRR30XR510N 2
32S00066 B5 01 SCREW M3 P0.5L10 MSRR30XR510B 2
32S00067 B5 01 NUT M3 P0.5 NUTM30XPR5HS 4
32S00068 B5 01 TOOTH WASHER D3 WSRO0632R5WS 4
32S00069 B5 01 CHASSIS IBZ10 STCIBZ-10XZB 1
32S00070 B5 01 TRANS 120V IBZ10 TRMBEX158XX 1
32S00071 B5 01 TRANS 230V IBZ10 TRMBEX158XX 1
32S00072 B5 01 POWER SWITCH SWRNNBB2NQ1A 1
32S00073 B5 01 CERAMIC CAP0.01U CCR103A40ZYS 1
32S00074 B5 01 AC SOCKET ACS3QKPUM102 1
32S00075 B5 01 POWER CABLE TIE PPTSRBFTL7K8 1
32S00076 B5 01 KNOB RKN-20BK RKNBKWH18R20 5
32S00077 B5 01 PUSH KNOB BK PKNS050510B4 PKN-4 1
32S00078 B5 01 SOLDERING PLATE SPTSDPXXTP-1 1
32S00079 B5 01 SCREW BK M4 P0.7 MSRU40XR710B 2
32S00080 B5 01 SCREW NI M4 P0.7 MSRU40XR712N 1
32S00067 B5 01 NUT M3 P0.5 NUTM30XPR5HS 2
32S00083 B5 01 NUT M4 P0.7 NUTM40XPR7HS 4
32S00084 B5 01 TOOTH WASHER D4 WSRO0844R5WS 4
32S00068 B5 01 TOOTH WASHER D3 WSRO0632R5WS 2
32S00086 B5 01 WASHER10DX4.2DX1 WSRF104210WS 1
32S00087 B5 01 CABLE TIE PPTCBTN08025 3
32S00088 B5 01 LABEL GND LABWHBKAG001 1
32S00089 B5 01 HEATSINK TUBE40M PPTHST251240 1
32S00090 B5 01 HEATSINK TUBE15M PPTHST040215 1
32S00091 B5 01 187 CONNECT WIRE HSN17XX1402A 1
32S00092 B5 01 187 CONNECT WIRE HSN17XX060DA 1
32S00093 B5 01 FUSE 0.25A/250V FUS520NSVR25 230V/240V 2
32S00094 B5 01 FUSE T0.5A/250V FUS520NFVR50 100V/120V 2
32S00095 B5 01 SPEC LABEL LABWHORBF001 2
32S00096 B5 01 CABINET IBZ10 BOXIBZ-10651 1
32S00097 B5 01 SPEAKER IBZ10 SPKIBZ-10X0１ 1
32S00098 B5 01 CORNER PCN-7 PCNPEXBK2807 8
32S00099 B5 01 STRAP HANDLE HDP190P23603 HDP-3 1
32S00100 B5 01 HANDLE CLAMP HDCSTEKBLK04 HDC-4 2
32S00101 B5 01 RUBBER FOOT PPTRFT112001 RUB-1 4
32S00102 B5 01 POWER CODE UL GA-1040RC-5 1
32S00103 B5 01 POWER CODE JP GA-1040RC-5
32S00104 B5 01 POWER CODE EU PWCE-DBH5V3A 1
32S00105 B5 01 POWER CODE ITALY GA-1040RC-5
32S00106 B5 01 POWER CODE UK GA-1040RC-5 1
32S00107 B5 01 POWER CODE SWISS GA-1040RC-5
32S00108 B5 01 LOGO PLATE PLGBKSVIBN0C IBANEZ SILVER 1
32S00109 B5 01 SCREW BK M4 P0.7 MSRU40XR715B L15 4
32S00110 B5 01 SCREW BK M4 P0.7 MSRS40XR725B L25 6
32S00111 B5 01 TAPPING SCREW TSRS25X08WDB BK2.5×8 2
32S00112 B5 01 TAPPING SCREW TSRS35X10WDB BK3.5×10 16
32S00113 B5 01 TAPPING SCREW TSRS35X20WDB BK3.5×20 2
32S00114 B5 01 TAPPING SCREW TSRS35X28WDB BK3.5×28 2
32S00115 B5 01 TAPPING SCREW TSRS40X18WDB BK4×18 4
32S00116 B5 01 PLASTIC WASHER WSRP174530BP 4
32S00117 B5 01 INSTRUCTION MANUAL IBZ10 1
32S00118 B5 01 WARRANTY CARD JP GRTIBZIBZ10A 1
32S00119 B5 01 LABEL-WARNTY CRD LABWHBKBD028 2
