18
MODEL No. : VBG
The aforementioned equipment fully conforms to the protection
requirements of the following EC Council Directives.
89/336/EEC : ELECTROMAGNETIC COMPATIBILITY
93/68/EEC : LOW VOLTAGE DIRECTIVE
■ OUTPUT POWER : 5W
■ POWER CONSUMPTION : 19W
■ INPUT INPEDANCE
GUITAR INPUT : 1MΩ
EFFECT RETURN : 1MΩ
■ EQUALIZATION
TREBLE ±12dB 4kHz
MIDDLE ±12dB 1.2kHz
BASS ±12dB 100Hz
PRESENCE -0, +12dB
7kHz
■ SPEAKER DRIVER : 6.5” / 4Ω 30W (MAX)
■ SIZE : 300(W) × 280 (H) × 240 (D)mm
■ WEIGHT : 7.8kg
■ PRE TUBE : 12AX7
■ POWER TUBE : 6L6GC
