Ibex TX31 Mini Round Baler with Net Wrap - Operator’s Manual 19
5.3.4 Pickup Suspension
The pickup is suspended with two (2) springs (Figure 42, A), one on each side. The length of the spring
should be approximately 1 7/8 inches (48mm) when the pickup is released into working position. Tension
can be adjusted if necessary by adjusting the position of the nuts (B).
Figure 42 Left side of baler
