Performing Common Tasks
Defining a Hot-Spare Drive
You can use the Administration and Monitoring program or the
ServeRAID configuration program to define a hot-spare drive. By
using the Administration and Monitoring program from your active
operating system desktop, you do not have to restart the server.
Refer to the README file on the Device Driver/Administration and
Monitoring diskette for instructions for your operating system.
You can define a hot-spare drive from the Create/Delete
Array/Log. Drive menu or the Rebuild/Device Management menu
(see “Defining the State of a Drive” on page 108).
To define a drive as a hot-spare drive from the Create/Delete
Array/Log. Drive menu:
1. Start the server using the ServeRAID configuration program (see
“Starting the ServeRAID Configuration Program” on page 86).
2. Select Create/Delete Array/Log. Drive from the Main Menu.
The following screen appears.
BayBay
ArrayArray
Ch 2Ch 1
Bay
Array
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Ch 1 Ch 2 Ch 3
CDR
Create/Delete Array
1. Help
2. Delete Disk Array
3. Create Disk Array
4. Define Logical Drive
5. Define/ndefine Hot-spare Drive
6. Delete Logical Drive
7. Eit
SelectachoiceusingthepArrow()andDownArrow()keysandpressEnter.
Press Esc to return to previous menu.
A
A
ONL
ONL
B
B
C
C
A
A
ONL
ONL
B
B
C
C
A
ONL
B
A
ONL
C
C
TAP
SHS
HSP
DHS
B
RBL
RDY
ONL
DDD
ONL ONL
ONL
ONL ONL
ONL
ONL ONL
ONL
IBM PC ServeRAID Adapter Disk Array Configuration Ver. 1.XX
Adapter Number: 1 Bus Number: 0 Host ID = Null Config
