Using the Mini-Configuration Program
Viewing Configuration Information
The View Configuration choice allows you to view the number and
size of logical drives installed. It also displays the RAID level,
current state, stripe size, write policy, read ahead status, and the
creation date for each logical drive.
Press any key to continue
IBM PC ServeRAID Adapter Disk Array Mini-Configuration Ver. 1.XX
View Adapter Configuration Information
No: 1 Bus: 0 Slot: 14
Size RAID Current Stripe Wrt Read Date Created
(MB) Level State Size Pol Ahead mm/dd/xx
Logical
Drive
Logical
Drive
0
1
2
3
4
5
6
7
100
100
100
100
100
99
200
300
OKY
OKY
OKY
OKY
OKY
OKY
OKY
OKY
8K
8K
8K
8K
8K
8K
8K
8K
WT
WT
WT
WB
WB
WT
WT
WT
NO
NO
NO
NO
NO
NO
NO
NO
01/18/96
01/18/96
01/18/96
01/18/96
01/18/96
01/18/96
01/18/96
01/18/96
5
5
5
5
5
1
5
1
Using Advanced Configuration Functions
The Advanced Functions choice allows you to reset the ServeRAID
adapter, initialize the configuration, and import the configuration
from drives.
 Reset the Adapter resets the adapter configuration values to the
factory defaults.
 Initialize Configuration restores the factory default settings and
sets all functional, connected hard disk drive states to the Ready
(RDY) state.
 Import Configuration from Drives reads the configuration
information from the drives and copies it to NVRAM and the
EEPROM modules on the adapter.
Chapter 3. Configuring the Disk Array 135
