Page #12 background image
Workgroup Switches Token-Ring
www.networking.ibm.com
129
C
8270 Universal Feature Cards
4-Port Token-Ring Enhanced Part number: 85H5092
UTP/STP Cabling:
UTP/STP via RJ-45 connectors
Supports Token-Ring STP cabling and category 3, 4 or 5 Token-Ring UTP cabling
Ports: 4 Token Ring, half-duplex (HDX) or full-duplex (FDX)
Data rate: 4- or 16-Mbps HDX or 32-Mbps FDX
2-Port Token-Ring Part number: 85H5087
Enhanced Fiber Cabling: Multimode fiber via ST connectors
Ports: 2 Token Ring, HDX or FDX
Data rate: 4- or 16-Mbps HDX or 32-Mbps FDX
1-Port ATM Token-Ring II MMF* Part number: 86H2762
Cabling: Multimode fiber via an SC connector
Ports: 1 ATM (LANE)
Data rate: 155 Mbps
MSS Client MMF*
1
Part number: 85H4596
Cabling: Multimode fiber via SC connectors
Ports: 1 ATM (LANE, CIP, NHRP)
Data rate: 155 Mbps
MSS Client SMF*
1
Part number: 85H4599
Cabling: Single-mode fiber via SC connectors
Ports: 1 ATM (LANE, CIP, NHRP)
Ports: 1 ATM (LANE, CIP, NHRP)
Data rate: 155 Mbps
MSS Domain Client* Part number: 85H9303
Cabling: N/A
Ports: N/A
Data rate: N/A
Publications ATM Multimode Fiber Universal Feature Card Planning and Installation Guide, GA27-4156
MSS Client Universal Feature Card Planning and Installation Guide, GA27-4170
MSS Domain Client Universal Feature Card Planning and Installation Guide, GA27-4171
2-Port Fiber and 4-Port UTP/STP Token-Ring Enhanced Universal Feature Cards Planning
and Installation Guide, GA27-4168
* Limitations: Maximum of two UFCs in this set may be installed in an IBM 8270. There may also be usage consideration associated with some
of these combinations.
1
The MSS Client (MMF and SMF) UFCs each occupy two slots in an 8270. All of the other UFCs occupy one slot each.
