Item Description Item Description
1 Rack 9 Brace hinges
2 Bracket screw, M5 x 16 mm 10 Brace
3 Bracket 11 Side-cover securing screw mount
4 Brace latch bracket screw, M8 x
20 mm
12 Spacer
5 Brace latch bracket 13 Spacer screw, M8 x 20 mm
6 Hinge 14 Side cover washer
7 Hinge screw, M8 x 20 mm 15 Side cover securing screw, M5 x
16 mm
8 Brace thumbscrew
Figure 58. Ruggedized kit parts, feature code 6080
To remove the triangular brace, complete the following tasks:
86
Power Systems: Racks and rack features
