Figure 87. Ground points on the rack frame
Earth (ground) bonding the side covers to the rack frame
The rack side covers shipped from IBM are already grounded. If you remove and replace the side covers,
ground the covers again by installing the bolts.
Door ground connection points
The earth (ground) connection points on the front and rear doors are located in each of the hinge side
corners.
About this task
The connection points are identied by the international earth (ground) symbol.
The following gure shows a ground connection point on the door.
Racks and rack features
125
