IBM 8185 - ThinkCentre M50 - 256 MB RAM User Manual

To install an adapter:
1. Remove the cover. See “Removing the cover” on page 9.
2. Pivot one of the drive bay latch handles toward the front of the computer and
then pivot the drive bay cage upward, as shown, until it is latched in the up
position. Repeat this procedure for the remaining drive bay.
3. Remove the support bar by pulling it outward from the computer.
4. Remove the adapter-slot-cover latch and the slot cover for the appropriate
expansion slot.
5. Remove the adapter from its static-protective package.
6. Install the adapter into the appropriate slot on the system board.
Chapter 1. Types 8185, 8186, 8192, 8413, and 8430 13

IBM 8185 - ThinkCentre M50 - 256 MB RAM Specifications

General

Brand	IBM
Model	8185 - ThinkCentre M50 - 256 MB RAM
Category	Desktop
Language	English
