IBM 8408-E8E Site And Hardware Planning

8. Four independent SAS adapters to one ESLL or ESLS storage enclosure through a mode 4 connection.
v For SAS adapter pairs, you must attach the cables to the same port on both adapters.
v Connection by using SAS X12 cables to connect to the ESLL or ESLS storage enclosure.
v Supported only on AIX and Linux systems.
Figure 101. Mode 2 connection of one ESLL or ESLS storage enclosure by using X12 cables to two pairs of SAS
adapters
Site and hardware planning 171
