IBM 900 - Page 101

Channel
Interface-out
Cable
Black
Gray
BUS-out
TAG-out
TAG
Terminator
2282676
BUS
Terminator
2282675
Wrap
(PN 7IF1184)
V-Cable
Black
Figure 3-10. Channel Interface-out Wrap Test Connections
Chapter 3. Multiaccess Enclosure Problem Determination 3-31
