IBM 900 - Page 100

Channel
Interface-in
Cable
Channel
Interface-out
Cable
Gray Black
BUS-in BUS-out
TAG-in TAG-out
TAG Wrap
8575338
TAG
Terminator
2282676
BUS Wrap
8575337
BUS
Terminator
2282675
V-Cable
Black Gray
Figure 3-9. All Cables Wrap Test Connections
3-30 3746-9X0: MAE Installation and Maintenance
