Channel
Interface-in
Cable
Gray Terminator
(PN 25L 4747)
BUS-in
TAG-in
TAG Wrap
(PN 8575338)
BUS Wrap
(PN 8575337)
V-Cable
Black Gray
Figure 3-8. Channel Interface-in Wrap Test Connections
Chapter 3. Multiaccess Enclosure Problem Determination 3-29
