MAE
MAE
or
Figure 3-17. Three Adapters Attached to One Channel
MAE
3172
or
Figure 3-18. IBM multiaccess enclosure Parallel Channel Adapter on a Channel with a
3172 Connected to a Channel Interface Assembly
Installing Channel Feature 3299
Note: Use the field electrostatic discharge (ESD) kit when you are handling
adapters. Guidelines for using the ESD tools are included inside the kit.
1. Verify that the new feature (and feature code) you are installing to make
sure that the customer’s adapters are supported. The feature code
appears on the Bill of Materials included with the miscellaneous
equipment specification (MES) under the heading “Bill Title.”
Because many adapter types are supported, only certain combinations
are valid. You might be trying to add an MES that requires another
Chapter 3. Multiaccess Enclosure Problem Determination 3-39
